Hot Glue Labeling Machine

How it Works:
The rotary hot glue labeling machine automatically transfers the bottle to the rotary mechanism through the screw, The labeling machine starts to run automatically after receiving the bottle feeding signal fed back by the detection device. After the label passes through the tensioning mechanism and the rectifier, it enters the label cutting mechanism to cut the label into the specified length.
Application:
Widely used in beverage industry, food, condiment, cosmetic and other industries
Advantages:
Operation and maintenance is simple;  Design for hot melt adhesives; Max. speed up to 30000BPH
  • PESTOPACK
  • One Year and Life-Long Technical Support
  • Engineers Available to Service Overseas
  • Beverage industry, food, condiment, cosmetic and other industries
  • Full Automatic
  • Label on round, oval, square, containers like plastic, metal, glass etc.
Availability:
Quantity:

Product Description

PESTOPACK-Banner1

HOT GLUE LABELING MACHINE VIDEO






























PRODUCT OVERVIEW


Hot glue labeling machine-product overview


PRODUCT DESCRIPTION



The rotary hot glue labeling machine automatically transfers the bottle to the rotary mechanism through the screw, The labeling machine starts to run automatically after receiving the bottle feeding signal fed back by the detection device. After the label passes through the tensioning mechanism and the rectifier, it enters the label cutting mechanism to cut the label into the specified length. The cut labels are transferred to the labeling mechanism by vacuum adsorption. The rotating labeling mechanism turns over the gluing mechanism, and pastes the labels with hot melt adhesive on both ends of the head and tail, and sticks them on the bottle of the rotary mechanism. The labeling process is completed after the bottle with the label is brushed flat by the labeler. At the same time, the running speed of the equipment (stop or run) is controlled through the detection point set by the bottle outlet chain.


FEATURES


✅ Through the optimized design of the structure, the number of wearing parts is minimized and its service life is improved.

✅ The configuration parts of different bottle types and labels can be replaced within 10 minutes.

✅ The adjustment process of the moving and fixed cutting knives is simple, the cutting performance is high, and the service life is high.

✅ The rotary hot melt adhesive labeling machine has strong adaptability to labels through the optimized design of label conveying mechanism and control system.

✅ Through the optimized design of the glue supply system and the glue rolling mechanism, it has strong adaptability to hot melt adhesives.


TECHNICAL PARAMETERS



Power

380V 50HZ 8KW

Dimension

3000mm×2500mm(Can customize)

Speed adjustment method

Stepless speed regulation

Labeling accuracy

±0.5mm

Max. width and height of label

150mm width

500mm length

Max. diameter of label

600 mm

Inside label roller diameter

152mm

Gluing temperature

120~160℃

Product scope

Label on round, oval, square, containers like plastic, metal, glass etc.

Label scope

OPP film label, paper-plastic composite film label, paper label

Container diameter

40mm-100mm

Labeling speed

12 stations    12000pcs/H

16 stations    18000pcs/H

24 stations    24000pcs/H

Weight

About 3000 Kg

DETAILED PICTURES

Hot glue labeling machine-detail picture


APPLICATION


Hot glue labeling machine-application

WARRANTY AND SERVICE


✅ One-year warranty.During which if any parts fault without human broken, we will courier to your replacing parts with replacing instructions, all at our cost.

✅ We will also can send you complete installation and operating tutorial videos before shipment.Remote assistance by video call or meeting is available as well.

✅ We welcome your engineer to our factory for training if you are willing to.

✅ We also can send technical staff if desperately needed, but engineer salary and flight ticket, visa application, travelling, board and lodging shall be at buyer's account.

✅ A set of spare parts will be shipped with machines for free. If any other spare parts needed, we will sell with very reasonable cost.

✅ Lifelong technical support. If you have any problem or fault about machine, you can contact us at any time by mail or by call. We will feedback you and give solution in the shortest time.


Company Profile

PESTO is a manufacturer of design,produce,sale and service for liquid filling machines,bottle capping machine,labeling machine,boxing machine and other packaging machines.With rich industry experience,we offer the most economic cost and best solution for our customers.No matter viscous or non-viscous liquid,PESTO will offer the most suitable solution.

As a packaging machine supplier,PESTO produces complete filling equipment in kinds of industries:
-Water and beverage

-Food and sauce
-Oil products(edible oil, mustard oil, cooking oil, lubricant oil, motor oil, engine oil ect.)
-Personal care(shapoo, lotion, cream ect.)
-Cosmetic and beauty(lipstick, lipbalm, mascara, compact powder ect.)
-Household products(bleach, detergent, hand sanitizer ect.)
-Agriculture products -Paints,stains and sealants
-E-cigarette


PESTOPACK Machinery-company profile(1)

FAQ

Q: How can I be sure to get assurance after payment?
A: In China, there is anti-money laundry policy, for which the government strictly manages every payment from abroad. The payment you made will firstly go to their managing account,and only when we submit bill of loading to them, payment will be released to us; the payment will be returned to you or pended by State Administration of Foreign Exchange,SAFE. if we are not able to make shipment and submit bill of lading within lead time.

Q: How can I be sure the machine will absolutely work for my product?
A: We will test run the machine once the building completes for 10 minutes, with your sample product ( when sample product is a must) and send you test run video to prove the machine works well and stable, for your product, before balance payment and shipment.

Q: Will you send technical staff to help me with installation and operation training?
A: The machine will be packed with little disassembly in one plywood crate, so they will be plug and use type, no need special installation. We will also send you complete installation and operating tutorial videos before shipment.Remote assistance by video call or meeting is available as well. In rare cases, we can send technical staff if desperately needed, but engineer salary and flight ticket, visa application, travelling, board and lodging shall be at buyer's account.

Q: How many years warranty and how do I do the machine repairing & maintenance?
A: One-year warranty from the date of shipment, during which if any parts fault, we will courier to your replacing parts with replacing instructions, all at our cost. The replacing is simple and easy to be completed by anybody. The machines are maintenance free types, some daily lubrication will prolong the service life though.

Q: When can i expect my email or questions to be replied?
A: Our working time is 9:00am--18:00pm Monday--Saturday, any email shall be replied within 24 hours normally. For an enquiry, the most recommended way of contact is by email, by sending your final product&photos to our email,due to our possible time difference.
