Automatic Water Filling Machine 18000BPH

Automatic water filling machine is mainly used for filling plastic PET bottled water such as purified water, drinking water, mineral water, etc. It integrates the three functions of washing, filling and capping.
  • CGF40-40-12
  • PESTOPACK
  • One Year and Life-Long Technical Support
  • Engineers Available to Service Overseas
  • Mineral water, drinking water, pure water, spring water, soda water, purified water
  • Liquid
  • Full Automatic
  • 18000 bottles per hour
  • PET bottles
  • Food grade stainless steel 304
Availability:
Quantity:

Product Description

PESTOPACK-Banner1





PICTURE OF AUTOMATIC WATER FILLING MACHINE


Automatic water filling machine picture


DESCRIPTION OF AUTOMATIC WATER FILLING MACHINE


This automatic water bottle filling machine CGF40-40-12 is a unique design combining the three parts of bottle washing, filling and capping in one. Washing filling capping 3 in 1 can decrease main power, save space and diminish the air pollution among three machines. The automatic water bottling machine is easy to change the shape of bottles, which can be done by changing the thumb wheel without adjusting the height of the machine.The automatic water filling machine case and the parts contacting with the materials are made of stainless steel which ensures the good external look and easy washing. Each automatic water bottle filling equipment element that contacts with the liquid is made of high quality Stainless steel 304, if needed,Stainless steel 316 is also available.The water filling and capping machine adopts bottle neck holding transmission technology to realize fully automatic rinsing, filling and capping. Most elements of the electrical system use famous international brand, for example,Mitsubish, Siemens brand . It obtains the advantages of good abrasive resistance,high stability,low failure rate, etc.


FEATURES OF AUTOMATIC WATER FILLING MACHINE


✅ The automatic water filling machine uses direct connection technology between air conveyor and in-feeding star-wheel to substitute in-feeding screw and conveyor to ease the process of bottle-size-changing.

✅ Neck-hanging technology is applied in bottle transportation of the automatic water bottle filling equipment. Instead of traditional star-wheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only arch board and star-wheel such little nylon parts need to be changed.

✅ Specially-designed rinsing grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution in this automatic water filling machine.

✅ Rapid gravity filling valve with high flow makes filling faster with accurate liquid level and without any liquid loss.

✅ Splint of star-wheel using twist descending way to simplify the process of bottle-size-changing.


TECHNICAL PARAMETERS


Whether you are a small water business or a big water business, we always have the best automatic water filling machine solution for you. Our production capacity ranges from 3000-24000BPH. If you are not satisfied with the 18000BPH capacity, please feel free to contact our professional sales to help you replace the appropriate new solution.

Model
CGF40-40-12
Rinsing heads 40
Filing heads 40
Capping heads 12
Filling volume 200ml 350ml 500ml 600ml 900ml 1000ml 1500ml 2000ml
Capacity(b/h, 500ml) 17000-18000
Power(KW) 7.5
Dimension(mm) 4600*2800*2900
Weight(kg) 8500



DETAILS OF AUTOMATIC WATER FILLING MACHINE


We have CNC processing equipment, cutting machine, bending machine, punching machine to strictly control the precision and quality of parts processing in automatic water filling equipment. State-of-the-art technology to improve filling accuracy and reduce errors.


Automatic water filling machine-air conveyor

Air conveyor

Automatic water filling machine-washing part

Washing part

Automatic water filling machine-filling part

Filling part

Automatic water filling machine-capping part

Capping part

Automatic water filling machine-cap elevator

Cap elevator

Automatic water filling machine-Cap sterilizer

Cap sterilizer


FUNCTION OF AUTOMATIC WATER FILLING MACHINE


Washing Station in automatic water filling machine

1. In this automatic water filling and capping machine, it adopts the direct connection technology between the air duct and the bottle feeding wheel, the bottle feeding screw and conveyor chain are eliminated, and the bottle shape is simple and easy to change.

2. The high-efficiency nozzle is adopted, and the cleaning water is sprayed at a specific angle, which can clean any part of the inner wall.

3. The high-speed line adopts bottle clamp transmission technology, the bottle shape changes more freely, and the internal working surface of the unit is more concise.


Filling Station in automatic water filling machine


1. The three-in-one unit completes the three processes of bottle washing, filling and capping at one time, with little bottle wear, accurate and stable transmission, and convenient bottle type replacement.

2. The specially designed all-stainless steel bottle washer bottle clamp is sturdy and durable, and does not touch the threaded part of the bottle mouth to avoid secondary pollution of the bottle mouth.
3. High-speed and large-flow gravity filling valves are used in automatic water filling machine, fast filling speed, accurate liquid level without liquid loss.


Capping Station in automatic water filling machine


1. All parts in contact with liquid of automatic water filling and capping machine are made of high-quality stainless steel materials or food-grade engineering plastics, which meet the national food hygiene standards.

2. The bottle bottom support plate of the bottle output wheel adopts a spiral descending method, and the height of the bottle conveyor chain is not required to change the bottle shape.


AUXILIARY EQUIPMENT


Automatic water filling machine-Water treatment

Water treatment system


We have two types of  pure water treatment and mineral water treatment.Use high quality stainless steel for tanks, pipes and connectors; Online type pressure auto self-protection device; System safe protecting and alarm system

automatic water filling machine-bottle blower

Bottle blower


We have different types of semi automatic and full automatic bottle blowing machine with different capacity. The machine can produce PET Bottles such as: water, beverage, wine, soybean, vinegar bottles and so on.

automatic water filling machine-Labeling-machine

Labeller


We have different types of labeling machine. Like shrink sleeve labeling machine, OPP glue labeling machine, double sides labeling machine. Shrink wrapping machine is mostly used for  water production line.

automatic water filling machine-Packing machine

Packing Machine


We have semi auto packing machine and full auto packing machine with different function. Like film shrink packing machine and carton packing machine. Shrink wrapping machine is mostly used for water production line.


LAYOUT OF AUTOMATIC WATER FILLING LINE


The automatic water filling line contains water purify system, bottle blowing machine, water filling machine, labeling machine and packing machine. The automatic water filling machine in water production line integrates bottle washing, filling and capping into one monobloc. The automatic water filling machine is suitable for mineral water, drinking water, pure water in PET bottles.

Automatic water filling machine-layout
