Water Bottle Filling Machine 10000BPH

How Water Bottle Filling Machine Works:
This rotary water bottle filling machine PTGF24-24-8 has three parts of stations. Washing-Bottles are placed on the conveyor and taken to the washing unit. Their inside and outside are washed with distilled water and dried. Filling-Bottles come to the filling unit by the conveyor and are filled into the bottle by different methods according to the filling liquid viscosity. Capping-Filled bottles are sealed in this section until they are opened by the end user.
Application:
Water, wine, juice and other thin viscous products.
Advantages:
Especially design for pet bottles filling. The bottle water filling machine has the capacity to handle bottles efficiently. It has advanced conveying technology, bottles do not fall off.
  • CGF24-24-8
  • PESTOPACK
  • Water bottle filling machine
  • One Year and Life-Long Technical Support
  • Engineers Available to Service Overseas
  • Water, Juice, Wine and other drinking product with thin viscous
  • Liquid
  • Full Automatic
  • 10000 bottles per hour
  • 350ml 500ml 1000ml 1500ml 2000ml
  • PLC+Touch screen
  • SUS304/SUS316(optional)
  • Water purify-Bottle blowing-Washing Filling Sealing-Labeling-Packing
  • Siemens/Schneider/Mitsubishi/AirTac/Delta/Can customized
Availability:
Quantity:

Product Description

PESTOPACK-Banner1


VIDEO OF WATER BOTTLE FILLING MACHINE





PICTURE OF BOTTLED WATER FILLING MACHINE


water bottle filling machine-picture


FINAL PRODUCT



water bottle filling machine bottle sample

Bottled water filling machine
 Bottle Type PET bottles or glass bottles
Volume 200-2000ml
Bottle diameter 50-115mm
Bottle height 160-320mm
 Production Capacity 3000-24000 bottles per hour
 Your Product Mineral water/Drinking water/pure water/spring water/purified water


WATER BOTTLE FILLING MACHINE FOR SALE


The water bottle filling machine for sale PTGF24-24-8 is a full-automatic multiple-function washing, filling and capping unit. It is used in washing, filling and sealing all kinds of non-air drinks such as fruit juice, oil & vinegar, wine, fruit wine, mineral water and pure water. The water bottle filling machine has features of unique design, new style, complete functions, multi-purpose, convenient in operation, beautiful construction, high automatization. It is one of the best water bottle filling machine in China.

✅ The key parts for washing, filling and sealing are made of high quality stainless material, with the features of advanced technology, completed system, reliable performance, easy in operation, etc

✅ The separated water filling machine is in straight line. The bottled water filling machine and capping machine can be changed.

✅ This water bottle filling machine is widely used in filling all kinds of non-carbonated drinks, such as fruit juice, fruit wine, mineral water, tea, and other liquid.

✅ This automatic water bottle filling machine applies for rinsing, filling and capping all kinds of plastic bottles, such as PVC, PET bottles etc.

 This bottled water filling machine is composed by auto bottle washing, filling machine, auto capping machine and conveyor system.


TECHNICAL PARAMETERS OF WATER BOTTLE FILLING MACHINE


Pestopack offers kinds of automatic water bottle filling machines for small and big business. Many small comapnies think they cannot afford an automatic, full professional plant to pack their water. Discover our automatic bottle water filling machine 2,000-3000 bottles per hour. The automatic bottled water filling machine 24,000 bottles per hour are the ideal solution for high-productivity companies that need to pack a large number of bottles each hour.


Model
CGF24-24-8
Rinsing heads 24
Filing heads 24
Capping heads 8
Filling volume 200-2000ml
Capacity(b/h, 500ml) 10000-11000
Power(KW) 4.5
Dimension(mm) 3100*2100*2800
Weight(kg) 4500



DETAILS OF WATER BOTTLE FILLING MACHINE



Water bottle filling machine-Washing part

Washing part

<1>All 304/316stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.
<2>304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.
<3> 304/316 stainless steel washing pump used in water bottle filling machine.

<4> It is washing function in mineral bottled water filling machine

Water bottle filling machine-Filling part

Filling part

<1> 304/316 Stainless steel high precision filling nozzle.
<2> Filling volume adjustable in fine rank, same liquid level after filling.
<3> All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean.
<4> 304/316 stainless steel filling pump used in water bottle filling machine.

Water bottle filling machine-Capping part

Capping part

<1> Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping.

<2> All 304/316 stainless steel construction for water bottle filling machine.

<3> No bottle no capping.

<4> Automatic stop when lack of bottle.



FLOW CHART OF WATER BOTTLE FILLING MACHINE LINE


When you start water business, and before you buy bottled water filling machine line, firstly you should know to produce mineral water or pure water. Water treatment will be different.


water bottle filling machine-water treatment_00

The whole process of bottled water filling machine line includes water treatment, bottle blowing machine, water filling machine, labeling machine and packing machine. You can contact our service team to get the best solution of water bottle filling machine line.

Water bottle filling machine line

LAYOUT OF WATER BOTTLE FILLING LINE


Pestopack provides turnkey solution of complete bottled water filling line. We design bottle water filling line layout for your factory.

Water bottle filling machine-layout



Company Profile


WATER BOTTLE FILLING MACHINE MANUFACTURER


PESTOPACK is an innovative and dynamic water bottle filling machine manufacturer in the design, manufacturing, maintenance and optimisation of water filling machine, beverage juice filling machine, carbonated drinks csd filling machine, beer filling machine, oil filling machine, sauce filling machine, household products filling machine, capping machine, labeling machine. We are specialized in bottled water filling machines and beverage filling machines over 12 years.

Our business scope are:

1.1-30 tons of pure water/mineral water treatment

2. Water bottle filling machine (PET bottle from 200 to 2000 ml)

Capacity from 2000-24000 BPH (based on 500 ml PET bottle) production line and turnkey project.

3. Juice three-in-one filling machine (PET bottle from 200 to 2000 ml)

Capacity from 2000-24000 BPH (based on 500 ml PET bottle) production line and turnkey project.

4. 3 in 1 filling machine for carbonated drinks (PET bottle from 200 to 2500 ml)

Capacity from 2000-24000 BPH (based on 500 ml PET bottle) production line and turnkey project.

5. Can filling and capping machine

6. Edible oil filling machine (PET or glass bottle filling machine)

7.5 Gallon Filling Machine

8. Bottle washer (glass or pet)

9. Bottle filling machine (glass or pet)

10. Bottle capping machine (glass or pet)

11. Labeling machine (PVC, glue or opp labels)

12. Shrink wrapping machine

13. Pallet packing machine

14. PET bottle blowing machine semi-automatic or fully automatic

15. PET bottle preform injection molding machine

16. PP, PVC, EVA extrusion blow molding machine

17. Cooling tunnel & bottle reversal sterilizer


Water bottle filling machine-company


Turnkey Solution


GET BEST WATER BOTTLE FILLING MACHINE PRICE FROM PESTOPACK


PESTOPACK invests the best resources in technical research, designing and implementing innovations in blow molding, water bottle filling machines, capping, labeling and packaging systems, responding and meeting different needs every day to achieve new goals. At the same time, we also provide customers with turnkey solutions for bottled water filling machines, from water plant bottling layout design, bottle and label design, water filling equipment manufacturing, bottled water production line setup, raw material supply to operator training. We have been doing our best to continuously meet the needs of customers and seek common development.


Bottled water filling machine-Raw material supply

Raw material supply

We can supply bottle preform, caps, label rolls with very reasonable price.

Bottled water filling machine-Layout-Design

Layout design

We will design and confirm the machine layout according to your factory sketch.

Bottled water filling machine-bottle and label design

Bottle design

Our designers can design bottle styles according to your requirement.

Bottled water filling machine-Label-Design

Label design

We can provide the label design according to the bottle size and style you want.


Our Service


SERVICE FOR WATER BOTTLE FILLING MACHINE


Pre-sale service for water bottle filling machine


-Inquiry and consultation support.

-Sample testing support.

-View our factory.

We promise our water filling machine for sale is new and never used. They are made of suitable materials and have a new design. quality, specifications and features meet contract requirements.



After-sales service for water bottle filling machine


-Training how to install the machine, training how to use the machine.

-Engineers can repair machinery overseas.

-After the equipment arrives at the customer workshop, place the equipment according to the floor plan we provide. we will arrange experienced technicians simultaneously perform equipment installation, commissioning and trial production to bring the equipment to its rated value the production capacity of the production line. The buyer needs to provide our engineer's round ticket, room and board, and salary.
