Automatic Lubricant Oil Filling Machine

Lubricant oil filling machines is an accurate volumetric fill way.Lubricant oil fillers are for a wide range of both thick also can be filled using this liquid filling machine. Piston fillers can be manufactured as automatic filling machines or they can be built to run in a semi-automatic fashion, making the filling machines useful to facilities with almost any level of production.
  • PESTOPACK
  • Lubricant oil filling machine
  • One Year and Life-Long Technical Support
  • Engineers Available to Service Overseas
  • Oil, Cleaning, Detergent, Seasoning, Cosmetics, Skin Care Products, Hair Care Products
  • Viscous Liquid
  • Full Automatic
  • 1000-4000BPH
  • Bottles and Cans 500ml-5000ml
  • PLC+Touch screen
  • SUS304/SUS316(optional)
  • Automatic Filling
  • Siemens/Schneider/Mitsubishi/AirTac/Delta/Can customized
Availability:
Quantity:

Product Description

PESTOPACK-Banner1


LUBE OIL FILLING MACHINE


Lubricant oil filling machine-product discription picture

PRODUCT DESCRIPTION

PESTOPACK lubricant oil filling machines utilize the latest technology to achieve both speed and accuracy. Our automated piston fillers are designed to provide customers with a flexible and easy to adjust automatic bottle filling machine, resulting in fast changeover times. lubricant oil filling machines are used in the food and beverage industry, household industry, pharmaceutical industry, chemical industry, e-liquid industry, and many more.


FEATURES OF LUBRICANT OIL FILLING MACHINE


✅ Use SUS304 grade material for all machine frame, SUS304/316 grade for liquid contacting parts as required.

✅ Use servo motor drives piston in lubricant oil filling machine, higher performance and higher filling accurate.

✅ Velumetric filling can be easliy adjusted in touch screen.  Parameters can be saved.

✅ Machine is easy cleaning. Tubes, connectors and corners are quick coupling. All lubricant oil filling machine meets GMP requirement.

✅ No bottle no filling. No liquid leaking when filling. Each filling nozzle can independently run.

✅ Electronic cabinet is independent. Wiring system layout is reasonable and tidy. It's very safety and easy for maintenance.



BENEFITS OF LUBRICANT OIL FILLING MACHINE


✅ High cost effective

Much higher effective than semi automatic and manual operation. That is an ideal filling machine for lubricant oil production.

✅ User freindly

Easily controlled by PLC and touch screen operation. Parameter data can be adjusted and saved in touch screen. Only one worker can operation without complex process.

✅ Easy cleaning

Machine without dead angle. Connection parts use quick coupling. No worries for cleaning.

✅ Wide application

This lubricant oil filling machine is mainly for viscous products in food and sauce, skin care, household, chemical industries, like oil, honey, tomato sauce, skin cream, detergent products.



TECHNICAL PARAMETERS


Type

PT-Z-4D

PT-Z-6D

PT-Z-8D

PT-Z-12D

Filling heads

4

6

8

12

Production speed
(bottles/hour)

1L:1000,5L:800

1L:1800,5L:1200

1L:2200,5L:1600

1L:3500,5L:2800

Filling accuracy

1-5L:±5ml

Filling range

500-5000ml

Suitable bottles

Round barrel:height:100-320mm;diameter:Φ100-180mm
Drum: length:100-200mm;width:40-80mm;height:150-300mm
Neck diameter:≤Φ30mm

Power

3KW

3KW

4KW

5KW

Power source

220/380V 50/60Hz

Air source

0.6Mpa

Dimension(mm)

1600×1100×2200

2000×1100×2200

2400×1100×2200

2600×1500×2200



DETAILES OF LUBRICANT OIL FILLING MACHINE

Lubricant oil filling machine-detailed pictures-1


Lubricant oil filling machine-detailed pictures-2


Lubricant oil filling machine-detailed pictures-3


Lubricant oil filling machine-detailed pictures-4


Lubricant oil filling machine-detailed pictures-5


Lubricant oil filling machine-detailed pictures-6




AUXILIARY EQUIPMENT FOR LUBRICANT OIL FILLING MACHINE




LUBRICANT OIL FILLING LINE LAYOUT


Servo Base Piston Filling Machine Layout

Company Profile

RELIABLE OIL FILLING MACHINE MANUFACTURER


PESTOPACK is an innovative and dynamic company in the design, manufacturing, maintenance and optimisation of oil filling machine. We are specialized in liquid filling machinery and packing machinery field over 12 years.

In order to meet the demand for oil filling machines that fit seamlessly into existing operations, we have developed a range of oil packaging equipment that is unmatched in reliability, efficiency and cost effectiveness. And, because we understand that every oil filling line has its own unique requirements, each of our oil filling machines is customized to the individual needs of our customers.

We place our clients first and custom best oil filling solution for them until they are satisfied.




After Sales Service

AFTER SERVICE FREOM OIL FILLING MACHINE SUPPLIER


Installation

We can dispatch our expert technicans to install lubricant oil filling machine. Service charge includes installation fee, travel expenses and meals.


Training

For getting the best lubricant oil filling machine performance, we offer on-site or at your factory training to dealers, machine operators, engineers and technicians.


Warranty

Provide efficient service, one year quality guarantee period, parts supply and quick feedback troubleshooting when lubricant oil filling machine maintenance.


Consulting

We provide free consulting. Professional sales will give you the most suitable solution. CAD drawing design of lubricant oil filling machine will be provided.


Technical Support

Offer 24/7 long life technical support. Just mail or give us a call, we will give quick feedback ASAP. Let you be free of worries.


Spare Parts

We will provide a set of spare parts in lubricant oil filling machine for free when shipping. Full-series quality parts can be ordered at any time with very reasonable price.
